GP-641 is a GPON ONT which is suited for FTTx residential applications. It complies with the ITU-T G.984 standard,
provides 2.488Gbps downlink & 1.244Gbps uplink bandwidth at network side, and provides four(4) GE port, one(1) FXS,
one(1) USB 3.0 and Wi-Fi 6 AX3000 WLAN port at user side.
The device provides high performance Data, Voice and Video services for individual users, SOHO (small office or family
office), small businesses, etc.
GP-641 is a GPON ONT which is suited for FTTx residential applications. It complies with the ITU-T G.984 standard, provides 2.488Gbps downlink & 1.244Gbps uplink bandwidth at network side, and provides four(4) GE port, one(1) FXS, one(1) USB 3.0 and Wi-Fi 6 AX3000 WLAN port at user side. The device provides high performance Data, Voice and Video services for individual users, SOHO (small office or family office), small businesses, etc.
| General |
Product Model :GP-641 ONT Type :GPON HGU Uplink :GPON Downlink :4*GE + 1*FXS + Wi-Fi 6 + 1*USB Flash: 256MB NAND Memory: 512MB DDR4 Operating Temperature : -5 to 45°C Storage Temperature :-20 to 70°C Operating :Humidity 5% to 95%，non-condensing Installation : Desktop & Wall-mounted Dimensions :190mm*135mm*33mm Net Weight :240g |
| PON |
PON Interface :GPON Connector :SC/UPC or SC/APC Data Rate Downlink: 2.488Gbps; Uplink: 1.244Gbps Standard :Compliance ITU-T G.984 Pout(Optical Transmitter Power) :0dBm~4dBm Psens(Optical Sensitivity): -28dBm~-8dBm |
| GE LAN |
Ethernet Interface : RJ45 connectors Standard Compliance : IEEE 802.3, 802.3u, 802.3ab Link:Half-duplex and full-duplex operations; 10/100/1000 BaseT auto-negotiation and manual configuration; MDI/MDIX auto detection Full duplex IEEE 802.3x flow control and half duplex back-pressure flow control |
| FXS |
VoIP Interface:RJ11 connectors |
| USB Interface |
USB 3.0 |
| Power |
Max Power Consumption : 10 watts Power Options :Wall adapter Wall Adapter :100-240VAC in, 50/60Hz 12VDC out, 1.5A |
| Indicators |
PWR / PON / LOS / Internet / USB / 2.4G / 5G / WPS / LAN / VOIP |
| Button |
Reset :Reset to factory default Wi-Fi :Turn on/off WLAN WPS : Push button to start WPS pairing LED : Turn on/off LED indicator Power switch : Push button power on or off |
| S/W Features-GPON |
ITU-T G.984.1-4 ITU-T G.988/TR255/TR156 15 TCONTs /256GEM ports 8 Egress queues per TCONT at least VLAN/ priority/VEIP gem mapping mode SN/LOID/SN+ Password authentication Performance monitoring: eth/Gem port Dying gasp |
| S/W Features-L3 Features |
PPPoE/Static IP/DHCP NAT/NAPT Port forwarding ALG, UPnP, DDNS IPv4/IPv6 dual stack, DS-Lite Static, and Default Routes Multiple services on one WAN port |
| S/W Features-L2 Features |
MAC learning (SVL)/aging Support max frame length to1518 bytes VLAN tagging for untagged packets Support VLAN 1-4094 VLAN transparent/translation |
| S/W Features-Multicast |
IGMP v2 (RFC 2236) and IGMP v3 (RFC 3376) IGMP snooping and IGMP Proxy MLD v1 |
| S/W Features-QoS |
Support 8 Queues with Strict Priority Ethernet port rate limitation 802.1ppriority SP/WRR Service flow classification |
| S/W Features-Diagnostic |
Ping Test Tracert Test |
| S/W Features-Management |
OMCI/WEB UI/TR069 Telnet/SSH Management with CLI commands Dual-system software backup and rollback upgrade by HTTP The configuration will not be lost after the upgrade |
| S/W Features-VPN |
L2TP/PPTP/IPSec |
| S/W Features-VoIP |
Call waiting, In-conditional Call Forward, Call Forward if Busy / no reply and 3rd-party calls. G711A/G711U/G729/G722 SDP protocol (RFC 2327 and RFC 4566) T.30/T.38/G.711 fax mode DTMF |
| Firewall |
Anti-DOS Anti port scan IPv6 Session Protection Anti SYN overflow Anti ICMP echo Anti ICMP redirect Anti-Land Anti-Smurf Anti-Winnuke Anti-Ping |
| S/W Features-Others |
Dynamic DNS UPnP SNTP DMZ Virtual Server |
| Wi-Fi |
Wi-Fi Protocol:2.4GHz supports 802.11b/g/n/ax 5GHz supports 802.11a/n/ac/ax Transmit Power:2.4GHz: 20dbm ; 5GHz: 23dBm Antenna : Dual-antenna MIMO (2.4G&5G), 5dBi WLAN Penetrate/Function: One reinforced concrete wall or two ordinary brick walls (non-reinforced concrete) Wi-Fi scanning and ambient RSSI level Support WDS Wireless Radio function to be turned on/off Mesh(Router version required) WLAN Access Capability :64 /SSID Channel: 2.4GHz (channel 1-13) ; 5GHZ (channel 36-161) WPS :WLAN terminal devices with WPS Push Button function establish connection within 2 minutes WLAN Security Function: WPA-PSK、WPA2-PSK、WPA3、WPA-PSK/WPA2-PSK AES、AES+TKIP Air Speed :574 Mbps (2.4GHz), 2402Mbps (5GHz) Multicast :WMM (Wi-Fi Multi Media) |
